CRT general type series six axis robot CRT-1850-6-C1

发布时间:2022-08-22浏览次数:272
  • CRT general type series six axis robot  CRT-1850-6-C1
  • CRT general type series six axis robot  CRT-1850-6-C1
  • CRT general type series six axis robot  CRT-1850-6-C1
  • CRT general type series six axis robot  CRT-1850-6-C1
  • CRT general type series six axis robot  CRT-1850-6-C1
  • CRT general type series six axis robot  CRT-1850-6-C1
  • CRT general type series six axis robot  CRT-1850-6-C1

CRT Spray type series six axis robot  CRT-1850-6-C1

Model:      CRT-1850-6-C1

Action type:  Multi joint type

Rated load :  20kg

Motion radius: 1850mm

Weight:      250kg

Number of axes : 6 axis

245 (4).jpg

245 (3).jpg

Model

CRT-1850-6-C1

Action type

Multi joint type

Rated load

20KG

Motion radius

                 1850

Repeatpositioning accuracy(mm)

±0.05

Protection level:

                  IP65

Scope of work

First axis

±17

Second axis

+135º/-70º

Third axis

+60º/-85º

Fourth axis

±150º

Fifth axis

+30º/-24

Sixth axis

±360º

Max speed

First axis

148º/sec

Second axis

148º/sec

Third axis

148º/sec

Fourth axis

222º/sec

Fifth axis

222º/sec

Sixth axis

222º/sec

Weightkg

250

axis

6

structural style

Series

connection

Installation method

Ground installation and bracket installation

Ambient temperature

5℃~45℃

Applicable industry

Material handling, parts transmission, stacking, deburring, cutting, etc
